0.60Pitch卧式WTB（2-20P全pin位已开）
国产替代件JST#0.6mm间距SMT针座
特点0.6mm间距 超小型 牢固 板对线用连接器
1. “业内超小”0.6mm间距压着接线连接器，1.65mm高，纵深2.0mm
2. 线缆抗拉拔强度大的牢固设计
3. BOX形压着端子设计，保证稳定接触
4. 压着外壳的缝隙处可防止半嵌合构造
5. 无卤素
应用领域国产替代XSR0.6（JST 0.6mm间距刺破线）主打超薄、微型、低电流场景，核心用在这些产品
无人机
• 飞控板、电调、摄像头、LED 灯板之间的信号连接
• 机身内部狭小空间的配线（轻、薄、短）
可穿戴设备
• 智能手表、手环：主板—屏幕、电池、心率传感器
• 蓝牙耳机：主板—喇叭、电池、充电触点
小型消费电子
• 指纹锁、智能门锁：主板—指纹模块、按键、电机
• 运动相机、摄像头模组：镜头—主板、闪光灯
• 超薄键盘、鼠标、遥控器内部连接线.
| 品号 | 品名 | PIN | 规格 | 每盘数量 |
| WT06001W-022R-001 | 0.60Pitch卧式WTB | 02 | 点镀金/卷带 | 4000 |
| WT06001W-032R-001 | 0.60Pitch卧式WTB | 03 | 点镀金/卷带 | 4000 |
| WT06001W-042R-001 | 0.60Pitch卧式WTB | 04 | 点镀金/卷带 | 4000 |
| WT06001W-052R-001 | 0.60Pitch卧式WTB | 05 | 点镀金/卷带 | 4000 |
| WT06001W-062R-001 | 0.60Pitch卧式WTB | 06 | 点镀金/卷带 | 4000 |
| WT06001W-072R-001 | 0.60Pitch卧式WTB | 07 | 点镀金/卷带 | 4000 |
| WT06001W-082R-001 | 0.60Pitch卧式WTB | 08 | 点镀金/卷带 | 4000 |
| WT06001W-092R-001 | 0.60Pitch卧式WTB | 09 | 点镀金/卷带 | 4000 |
| WT06001W-102R-001 | 0.60Pitch卧式WTB | 10 | 点镀金/卷带 | 4000 |
| WT06001W-112R-001 | 0.60Pitch卧式WTB | 11 | 点镀金/卷带 | 4000 |
| WT06001W-122R-001 | 0.60Pitch卧式WTB | 12 | 点镀金/卷带 | 4000 |
| WT06001W-132R-001 | 0.60Pitch卧式WTB | 13 | 点镀金/卷带 | 4000 |
| WT06001W-142R-001 | 0.60Pitch卧式WTB | 14 | 点镀金/卷带 | 4000 |
| WT06001W-152R-001 | 0.60Pitch卧式WTB | 15 | 点镀金/卷带 | 4000 |
| WT06001W-162R-001 | 0.60Pitch卧式WTB | 16 | 点镀金/卷带 | 4000 |
| WT06001W-202R-001 | 0.60Pitch卧式WTB | 20 | 点镀金/卷带 | 4000 |
